Description
NORTHROP GRUMMAN SYSTEMS CORPORATION DIV NAVIGATION AND MARITIME SYSTEMS DIVISION MS90310271, MS90310-271, M90310271, M90310-271, MILDTL8834, MIL-DTL-8834, MILS8834, MIL-S-8834, W41262K6100B6, W41262-K6100-B6, 0700358271, 07-00358-271, 2665361000, 266-5361-000, 6L.4612.42600-152882, 6L461242600152882, 8120851271, 812085-1271, 9132C30062, 9132C3006-2, 9352065, 935206-5, 5930-00-931-0516, 00-931-0516, 5930009310516, 009310516, BODY STYLE BUSHING MOUNT HAZARDOUS LOCATIONS/ENVIRONMENTAL PROTECTION DRIPTIGHT OVERALL LENGTH 0.458 INCHES MINIMUM OVERALL HEIGHT 1.898 INCHES MAXIMUM OVERALL WIDTH 0.354 INCHES MAXIMUM BUSHING LENGTH 0.458 INCHES MINIMUM AND BUSHING LENGTH 0.478 INCHES MAXIMUM BODY LENGTH 0.562 INCHES MAXIMUM BODY WIDTH 0.354 INCHES MAXIMUM BODY HEIGHT 0.572 INCHES MAXIMUM ACTUATOR STYLE ROUND ACTUATOR DIAMETER 0.240 INCHES MINIMUM AND ACTUATOR DIAMETER 0.246 INCHES MAXIMUM ACTUATOR HEIGHT 0.655 INCHES MINIMUM AND ACTUATOR HEIGHT 0.719 INCHES MAXIMUM ACTUATOR POSITION-ACTION RELATIONSHIP UP POSITION MOMENTARY AND ACTUATOR POSITION-ACTION RELATIONSHIP CENTER POSITION MAINTAINED AND ACTUATOR POSITION-ACTION RELATIONSHIP DOWN POSITION MOMENTARY MAXIMUM VOLTAGE RATING IN VOLTS 115.0 AC AND MAXIMUM VOLTAGE RATING IN VOLTS 50.0 DC MOUNTING SURFACE TO TERMINAL END DISTANCE 0.706 INCHES MAXIMUM INCLOSURE TYPE UNINCLOSED MOUNTING METHOD THREADED BUSHING NONPILE-UP CONTACT ARRANGEMENT 3 POLE, DOUBLE THROW, TWO POSITIONS MOMENTARY SINGLE SWITCH UNIT CONTACT LOAD CURRENT RATING AT MAXIMUM RATED VOLTAGE 1.000 AMPERES RESISTIVE DC AND CONTACT LOAD CURRENT RATING AT MAXIMUM RATED VOLTAGE 1.000 AMPERES INDUCTIVE DC AND CONTACT LOAD CURRENT RATING AT MAXIMUM RATED VOLTAGE 3.000 AMPERES RESISTIVE AC AND CONTACT LOAD CURRENT RATING AT MAXIMUM RATED VOLTAGE 1.000 AMPERES INDUCTIVE AC SPEC/STD CONTROLLING DATA MANUFACTURERS CODE 81349 NON-DEFINITIVE GOVERNMENT SPEC/STD REFERENCE MIL-DTL-8834 MANUFACTURERS CODE 96906 DEFINITIVE GOVERNMENT SPEC/STD REFERENCE MS90310-271 TEST DATA DOCUMENT 81349-MIL-DTL-8834 SPECIFICATION (INCLUDES ENGINEERING TYPE BULLETINS, BROCHURES,ETC., THAT REFLECT SPECIFICATION TYPE DATA IN SPECIFICATION FORMAT; EXCLUDES COMMERCIAL CATALOGS, INDUSTRY DIRECTORIES, AND SIMILAR TRADE PUBLICATIONS, REFLECTING GENERAL TYP TERMINAL TYPE AND QUANTITY 3 TAB, SOLDER LUG SPECIFICATION/STANDARD DATA 96906-MS90310-271 GOVERNMENT SPECIFICATION, UH-60 BLACK HAWK UNIQUE AVIONICS ARLEIGH BURKE CLASS DDG TICONDEROGA CLASS CG (47) HELICOPTER, ADVANCE ATTACK, AH-1W AN/USQ-225 FMS - AN/SYQ-13 COMMAND AND CONTROL SYSTEM FMS - MHC-51 CLASS MACHINERY AND SHIP CONTROL SYST MISSILE, AIR LAUNCH CRUISE (ALCM) AGM-86B AN/SPS-67 RADAR SUBMARINE ACOUSTIC SONAR SYSTEMS AIRCRAFT, F-16 HELICOPTER, CHINOOK, CH-47 LOS ANGELES CLASS SSN (688) AIRCRAFT, SOF (AC-130H, AC-130J, AC-130U, EC-130E, HELICOPTER, SEA KNIGHT H-46 HELICOPTER OBSERVATION (AHIP), OH-58D FMS - AIRCRAFT, HORNET F/A-18 FMS - BUILD FRIGATES CLASS SHIPS CH47( ) CHINOOK UNIQUE AVIONICS-QW TANK, COMBAT, FULL TRACK, EGYP INCR 7 TANK, COMBAT, FT, 120MM GUN (M1A1) AIRCRAFT, THUNDERBOLT II, A-10 AIRCRAFT, TOMCAT F-14 CONSOLIDATED TARGETS COMMON SYSTEMS HELICOPTER, MH-53E AIRCRAFT, EAGLE F-15 AIRCRAFT, HARRIER AV-8B AIRCRAFT, HERCULES C-130F HELICOPTER, LAMPS MARK III, SH-60B LANDING SYSTEM AUTOMATIC CARRIER, DUAL CHANNEL AN/BSY-1(V) ACOUSTIC SONAR AIRCRAFT, HORNET F/A-18 FMS - NEWPORT CLASS LST AN/SQS-53(A) SONAR DETECTING RANGING SET AH-64-D LONGBOW E2/C2 ALL SERIES AIRCRAFT LIGHT ARMORED VEHIC (TAMCN: E09487B) AIRCRAFT, C-2A (REPROCURED) AN/FRC-181 MILSTAR/AFSATCOM TERMINAL NON-TRIDENT EXTERIOR COMMUNICATION AIRCRAFT, HERCULES KC-130 TOW NIGHT SIGHT EQUIPMENT SET, AN/UAM-12 TANK, ABRAMS M-1 AIRCRAFT, PROWLER EA-6B COMPUTER, AN/UYK-43(V) JOINT STARS TARGET RADAR SYSTEM ADVANCED AIR TRAFFIC CONTR. & LAND. SYS (ATCALS) 4 AIRCRAFT, ORION P-3 HELICOPTER, UTILITY/SEARCH AND RECOVERY UH-1N AIRCRAFT, F/A-18, A - D, E/F, G (GROWLER) AIRCRAFT, STRATOLIFTER C/KC-135 HARPOON LAUNCHER HELICOPTER, COBRA/ATTACK, AH-1J HELICOPTER, HH-60 SONAR ACOUSTIC MISCELLANEOUS RECOVERY VEHICLE, FU HELICOPTER, SEAHAWK, H-60 INFANTRY CARRIER (STRYKER FIGHTNING VEHICLE) CONSOLIDATED GROUND SUPPORT EQUIPMENT TRIDENT EXTERIOR COMMUNICATIONS MISSILE, HELLFIRE HELICOPTER, H1 ALL VERSIONS BALLISTIC MISSILE EARLY WARNING SYS. (BMEWS) LANDING CRAFT UTILITY (LCUS) HELICOPTER, SEARCH AND RESCUE, HH-60H SONAR SETS, AN/BQS-14A/15 AIRCRAFT, AIRLIFTER C-17A LIGHT ARMORED VEHIC (TAMCN: E09477M) LIGHT ARMORED VEHIC (TAMCN: E09497M) AIRCRAFT, HAWKEYE E-2C FMS - KIDD CLASS DDG FMS - KNOX CLASS FF OHIO CLASS SSBN (TRIDENT) AIRCRAFT, B-1B AIRCRAFT, STRATOFORTRESS B-52 HELICOPTER, USCG SEARCH AND RESCUE, HH-60J TANK, COMBAT, FULL TRACK, EGYP M1A1 MISSILE, ALL-WEATHER ANTI-SHIP, HARPOON (AGM-84) HELICOPTER, CARRIER BASED ASW, SH-60F RADIO TRANSMITTER SET, AN/URT-23 (RTS) AGM-84H STANDOFF LAND ATTACK MISSILE (SLAM) NAVY COMMAND CONTROL & COMMUNICATIONS AIRCRAFT, AWACS, E-3A AN/ARC-208 (V) (AFCPT AIRBORNE) MILSTAR SATELLITE TRAINER, B-1B AIRCRAFT TA-4J AIRCRAFT
