Description
INTERSTATE ELECTRONICS CORPORATION DBA L-3 INTERSTATE ELECTRONICS DIV L3 INTERSTATE ELECTRONICS CORPORATION ONAN GENERATOR 485L TACS AIRCRAFT, EAGLE F-15 AIRCRAFT, GALAXY C-5 M22/03-00191FD, M220300191FD, MIL-PRF-22/3, MILPRF223, MILR223, MILR22-3, RP101FD751KK, JHP11171, JHP111-71, 1210043, 121-0043, 317-302-136, 6690037, 669-0037, 5905-00-643-5129, 00-643-5129, 5905006435129, 006435129, 317302136, BODY STYLE CYLINDRICAL BUSHING MOUNTED RELIABILITY INDICATOR NOT ESTABLISHED OVERALL LENGTH 2.332 INCHES MAXIMUM FIRST FLAT LENGTH 0.344 INCHES NOMINAL FLAT HEIGHT 0.211 INCHES MINIMUM AND FLAT HEIGHT 0.221 INCHES MAXIMUM BODY DIAMETER 1.680 INCHES MAXIMUM SHAFT DIAMETER 0.248 INCHES MINIMUM AND SHAFT DIAMETER 0.251 INCHES MAXIMUM SHAFT LENGTH 0.828 INCHES MINIMUM AND SHAFT LENGTH 0.922 INCHES MAXIMUM MOUNTING BUSHING LENGTH 0.328 INCHES MINIMUM AND MOUNTING BUSHING LENGTH 0.422 INCHES MAXIMUM BODY LENGTH 1.410 INCHES MAXIMUM OVERALL DIAMETER 2.260 INCHES MAXIMUM SHAFT STYLE ROUND, FLATTED ACTUATOR TYPE SINGLE SHAFT MAXIMUM STARTING TORQUE 40.00 INCH-OUNCES MAXIMUM STOP TORQUE 240.00 INCH-OUNCES NONTURN DEVICE LOCATION AT 12 OCLOCK NONTURN DEVICE RADIUS 0.485 INCHES MINIMUM AND NONTURN DEVICE RADIUS 0.515 INCHES MAXIMUM SCREW THREAD DIAMETER 0.375 INCHES NOMINAL SCREW THREAD SERIES DESIGNATOR UNEF SCREW THREAD QUANTITY PER INCH 32.0 TERMINAL LOCATION RADIALLY POSITIONED OVER LESS THAN HALF THE CIRCUMFERENCE MOUNTING METHOD STANDARD BUSHING ELECTRICAL RESISTANCE PER SECTION 750.000 OHMS SINGLE SECTION ROTARY ACTUATOR TRAVEL IN ANGULAR DEG 275.0 MINIMUM AND ROTARY ACTUATOR TRAVEL IN ANGULAR DEG 305.0 MAXIMUM AMBIENT TEMP IN DEG CELSIUS PER SECTION AT ZERO PERCENT RATED POWER 340.0 SINGLE SECTION POWER DISSIPATION RATING PER SECTION IN WATTS 25.0 HEAT SINK SINGLE SECTION RESISTANCE TOLERANCE PER SECTION IN PERCENT -10.0 TO 10.0 SINGLE SECTION ACTUATOR TRAVEL CONTROL FEATURE STOPS AMBIENT TEMP IN DEG CELSIUS PER SECTION AT FULL RATED POWER 25.0 SINGLE SECTION SPEC/STD CONTROLLING DATA MANUFACTURERS CODE 81349 NON-DEFINITIVE GOVERNMENT SPEC/STD REFERENCE MIL-PRF-22/3 MANUFACTURERS CODE 81349 DEFINITIVE GOVERNMENT SPEC/STD REFERENCE M22/03-00191FD TEST DATA DOCUMENT 81349-MIL-R-22 SPECIFICATION (INCLUDES ENGINEERING TYPE BULLETINS, BROCHURES,ETC., THAT REFLECT SPECIFICATION TYPE DATA IN SPECIFICATION FORMAT; EXCLUDES COMMERCIAL CATALOGS, INDUSTRY DIRECTORIES, AND SIMILAR TRADE PUBLICATIONS, REFLECTING GENERAL TYPE DA TERMINAL TYPE AND QUANTITY 3 TAB, SOLDER LUG SPECIFICATION/STANDARD DATA 81349-MIL-R-22/3 GOVERNMENT SPECIFICATION, SUPPORT EQUIPMENT, C-5 AIRCRAFT NIMITZ CLASS CVN FMS - KNOX CLASS FF 485L TACS AIRCRAFT, EAGLE F-15 GENERATOR 3KW DIESEL MILITARY STANDARD FAMILY AIRCRAFT, GALAXY C-5 SUPPORT EQUIPMENT, C-135 AIRCRAFT MERCY AND COMFORT HOSPITAL SHIPS CLASS TAH
