MS75021-1 Trailer Socket Military 12 Pin Brass Electrical Connector Mutt M998

5935008463883

$34.99

WHAT IS IT:

BRAND NEW SEALED MILITARY SURPLUS

SHIPS FREE, SHIPS FAST

****************************************

DETAILS - SPECS:

BODY STYLE 1G STRAIGHT SHAPE, EXTERNAL COUPLING

OVERALL LENGTH 1.680 INCHES NOMINAL

OVERALL HEIGHT 2.688 INCHES NOMINAL

OVERALL WIDTH 2.688 INCHES NOMINAL

CENTER TO CENTER DISTANCE BETWEEN MOUNTING FACILITIES PARALLEL TO HEIGHT 2.188 INCHES NOMINAL

DISTANCE BETWEEN CENTERLINES OF MOUNTING FACILITIES PARALLEL TO BODY WIDTH 2.188 INCHES NOMINAL

DISTANCE FROM MOUNTING SHOULDER TO FRONT FACE 0.787 INCHES NOMINAL

UNTHREADED MOUNTING HOLE DIAMETER 0.269 INCHES NOMINAL

NOMINAL THREAD SIZE 1.625 INCHES

THREAD CLASS 2A

THREAD QUANTITY PER INCH 18

THREAD DIRECTION RIGHT-HAND

NOMINAL THREAD LENGTH 0.667 INCHES

SHELL MATERIAL STEEL COMP 1010

SHELL MATERIAL DOCUMENT AND CLASSIFICATION QQ-S-630,GRADE C1010 FED SPEC SINGLE MATERIAL RESPONSE

SHELL SURFACE TREATMENT CADMIUM

SHELL SURFACE TREATMENT DOCUMENT AND CLASSIFICATION QQ-P-416,TY 2,CL 3 FED SPEC

CONTACT POSITION ARRANGEMENT STYLE ANCD 28-51 SINGLE MATING END

****************************************

CONDITION:

BRAND NEW

****************************************

BRAND:

****************************************

MPN:

MS75021-1

****************************************

CROSSOVER - INTERCHANGE - COMPATIBLE WITH:

MS750211, MS75021-1, MS750211P, MS75021-1P, BG26996, D76493, D7649-3, DKI731615, DKI73-1615, 1210110, 12101-10, 20859A, 2979780, 2HA24 , 3541, 6003602851P, 60-036028-51P, 6003603051P, 60-036030-51P, 7525173, 8376208, 5935-00-846-3883, 00-846-3883, 5935008463883, 008463883

****************************************

APPLICATION - USED ON IN - WHAT IS IT FOR:

12101-10 91340 MET-PRO CORPORATION

20859A 63810 WARNER ELECTRIC BRAKE AND CLUTCH CO HQ

2979780 12204 DAIMLER CHRYSLER

2HA24 45152 OSHKOSH CORPORATION

2HA24 75Q65 OSHKOSH DEFENSE, LLC

3541 36024 LIBBY POWER SYSTEMS LLC

60-036028-51P 77820 AMPHENOL CORPORATION DBA AMPHENOL AEROSPACE INDUSTRIAL

60-036030-51P 77820 AMPHENOL CORPORATION DBA AMPHENOL AEROSPACE INDUSTRIAL

7525173 91971 NELSON MANUFACTURING CO INC

8376208 19207 U S ARMY TANK AUTOMOTIVE COMMAND AMSTA-IM-MM

8376208 53335 UNIVERSAL LOGISTICS CORP CLARK DIV

BG26996 18990 EAGLE CRUSHER CO INC

D7649-3 5RQL2 DRS ENVIRONMENTAL SYSTEMS, INC. DBA D R S

D7649-3 94833 KECO INDUSTRIES INC.

DKI73-1615 98769 SENIOR OPERATIONS LLC DBA SENIOR AEROSPACE SSP

MS75021-1 96906 MILITARY STANDARDS PROMULGATED BY MILITARY DEPARTMENTS

MS75021-1P 96906 MILITARY STANDARDS PROMULGATED BY MILITARY DEPARTMENTS

12 TON CHASSIS SEMI TRAILER MINE RESISTANT VEHI (TAMCN: D00367K) (MRAP) SHOP EQUIPMENT, GENERAL PURPOSE REPAIR, TRLR, SEMI SEMI TRAILER LOWBED TRUCK,DUMP,7 TON WI CONSOLIDATED GROUND SUPPORT EQUIPMENT TRAILER, SEMI, FLAT BED;BREAKBULT/CONT TRANSPORTER SUPPORT EQUIPMENT, T-38 AIRCRAFT TRUCK TRACTOR,7 TON DOLLY SET, LEFT TRANS M-ATV UI WITH CROWS SEMITRAILER VAN ELECTRIC TRUCK,WRECKER 7 1/2 TON SEMI TRAILER VAN REFER SUPPORT EQUIPMENT, B-52 AIRCRAFT TRUCK TRACTOR MINE RESISTANT VEHICLE CS13 SNE TRUCK MULTI-MISSION LAUNCHER TRUCK,ARMORED,XLWB TRUCK,RTAA,XLWB M1062 TANKER, 7500 GAL. SEMI-TRAILER TRAILER, SEMI, TANK; 5000 GAL, BULK THIS WILL BE THE PARENT WSDC FOR ALL ARMY MRAP WSD 12 TON SEMI TRAILER STAKE HIMARS RE-SUPPLY VE TRAILER, SEMI (M986) & CHASSIS, TRAILER, SEMI (M99 TRAILER, SEMI (M172A1) ARMORED SECURITY VEHICLE, MODEL XM1117 TRAILER, SEMI (M870) OSHKOSH MRAP - ALL TERRAIN VEHICLE (M-ATV) HEATER, HOT OIL MINE RSISTNT AMBUSH PRTCTD ALL TERIN (M-ATV),L292 TRUCK, WRECKER, LVSR MRAP M-ATV UI UNDERBODY IMPROVEMENT MINE RESISTANT VEHICLE CS13 POP TRUCK, TRACTOR LVSR SUPPORT EQUIPMENT, T-37 AIRCRAFT TRUCK, WRECKER, ARMOR ARMAMENT WEAPONS SUPPORT EQUIPMENT (AWSE) TRAILER, SEMI (M872A1, M872A2, M872A3) LVSR CARGO TRUCK LAUNCHER TRAILER, SEMI (M860A1) TRUCK TRACTOR, ARMOR TRUCK,ARMORED,DUMP

****************************************
