Hydraulic Bilge Pump Unit Centrifugal Crane XM-1 Tank 4320010730082 12273263 XM22107 XM66131

4320010730082
  • $798.98


WHAT IS IT:

Hydraulic Bilge Pump Unit Centrifugal Crane XM-1 Tank 4320010730082 12273263 XM22107 XM66131

****************************************

CONDITION:

Brand New in Box

****************************************

BRAND:

CRANE PUMPS & SYSTEMS

****************************************

MPN:

19207-12273263-01

1ZDCL-12273263-01

****************************************

CROSSOVER - INTERCHANGE - COMPATIBLE WITH:

4320010730082, XM22107, 12273263, XM66131, 19207-12273263-01, 1ZDCL-12273263-01, 12273263-01, 12273263, 328517G01, 4320-01-073-0082, 01-073-0082, 010730082

****************************************

APPLICATION:

U S ARMY TANK AUTOMOTIVE COMMAND AMSTA-IM-MM 12273263 33654 HOWDEN FLUID SYSTEMS XM22107 01417 GENERAL DYNAMICS LAND SYSTEMS INC. DBA GENERAL DYNAMICS LAND SYSTEMS XM66131 01417 GENERAL DYNAMICS LAND SYSTEMS INC. DBA GENERAL DYNAMICS LAND SYSTEMS

***************************************

COUNTRY OF ORIGIN:

USA

****************************************

OTHER:

PRIME MOVER QUANTITY 1 MOUNTING TYPE BASE STAGE QUANTITY 1 DISCHARGE CONNECTION QUANTITY 1 DISCHARGE CONNECTION TYPE COMPRESSION TUBE MEDIA FOR WHICH DESIGNED HYDROCARBON FUELS AND OILS AND MEDIA FOR WHICH DESIGNED WATER, FRESH PUMP QUANTITY 1 END ITEM IDENTIFICATION 2350-01-061-2445 MAXIMUM DISCHARGE FLOW RATE 2.7 GALLONS PER MINUTE DISCHARGE PRESSURE 270.0 POUNDS PER SQUARE INCH GAGE TOTAL HEAD 15.000 FEET SUCTION LIFT 4.130 FEET AND SUCTION LIFT 4.370 FEET OPERATING SPEED AT RATED CAPACITY 2376.0 REVOLUTIONS PER MINUTE PUMPING ELEMENT OPERATING POSITION VERTICAL CENTRIFUGAL PUMP DESIGN MIXED FLOW CENTRIFUGAL PUMP IMPELLER QUANTITY 1 CENTRIFUGAL PUMP IMPELLER SUCTION TYPE SINGLE PRIME MOVER TYPE HYDRAULIC MOTOR
