Description
70121 Gates 3319-0071 20G3H Hydraulic Hose 1 1/4" 131 feet GLX Coupling
70121 20G3HXCTN
Product# # 33190071
G3H High-Temp hose is recommended for hydraulic oil lines, anti–freeze solutions or water.
- Recommended For: Hydraulic oil lines, anti-freeze solutions or water.
- For use with GLX™ Couplings [G44 Series] and MegaCrimp™ Couplings [G25 Series].
- Meets or exceeds requirements of SAE 100R3.
| Part # | 20G3HXCTN / 70121 |
| Product # | 33190071 |
| Description: | 70121 20G3HXCTN |
| Vacuum (In. Hg) | 15 |
| Minimum Bend Radius (in) | 10 |
| Minimum Bend Radius (mm) | 254 |
| Min. Burst Pressure (psi) | 375 |
| Inside Diameter (in) | 1.25 |
| Inside Diameter (mm) | 31.8 |
| Temperature Range | -40°F to +275°F (-40°C to +135°C) |
| Working Pressure (psi) | 375 |
| Length (m) | 37 |
| Outside Diameter (in) | 1.75 |
| Outside Diameter (mm) | 44.5 |
